ROCBIT PLATINUM HAMMER RANGE
Rocbit Drilling Equipment (Pty) Ltd. uses state of the art CAD systems coupled with computerized a machining technique and equipment to produce its comprehensive range of high quality down-the-hole percussion hammers. The range, manufactured from imported materials, is capable of drilling holes with diameters (3″) 79mm to (48″) 1220mm. Setting the new quality standards in the industry, the ROCBIT PLATINUM RANGE of conventional down-the-hole hammers are robust in construction, rugged, reliable and easy to maintain. The long life characteistics of these hammers ensure optimum performance, even in the most arduous conditions.
Product support; either in the from of spares or technical assistance, is available 24 Hours a day.
| Hammer | Ø mm | Length mm | Weight kg | Spanner flat | Thread |
|---|---|---|---|---|---|
| Platinum RH3 SD 3 | 80 | 731 | 20 | 64 | 2 3/8″ |
| Platinum RH3 330 | 80 | 698 | 19 | 64 | 2 3/8″ |
| Platinum RH4 SD 4 | 96 | 818 | 31 | 76 | 2 3/8″ |
| Platinum RH4 340 | 96 | 768 | 29 | 76 | 2 3/8″ |
| Platinum RH5 SD 5 | 116 | 902 | 50 | 89 | 3 1/2″ |
| Platinum RH5 350 | 116 | 902 | 49.5 | 89 | 3 1/2″ |
| Hammer | Ø mm | Length mm | Weight kg | Spanner flat | Thread |
|---|---|---|---|---|---|
| Platinum RH6 360 | 140 | 976 | 78 | 102 | 3 1/2″ |
| Platinum RH6 360 H/D | 145 | 976 | 85 | 102 | 3 1/2″ |
| Platinum RH8 SD 8 | 177 | 1005 | 138 | 140 | 4 1/2″ |
| Platinum RH12 SD 12 | 256 | 1115 | 303 | 191 | 6 5/8″ |
